Factory Price AMP UTP CAT6 UTP Cables Network Cable UTP CAT6 Patch Cord 1.5 M

Basic Info

Model NO.	patch cord
Application	Local Communication Cable, LAN Cable
Conductor Material	Copper
Cover Material	PVC
Type	Cat 5
Material Shape	Round Wire
Conductor Type	Solid
Wire Core Material	Bare Copper Wire
Certification	CE, ISO, RoHS, CCC
Model	Cat5e UTP
Brand	Cx-Cable
Size of Conductor	24AWG/26AWG
Numbers of Conductor	8
Insulation	HDPE
Jacket	PVC/PE
Color	Customers′request
Outer Carton Size	41*41*48cm
Test	Fluke Link
Transport Package	305m/Easy Pull Box, 2boxes/Carton
Specification	CE/SGS/ROHS/ISO
Trademark	OEM or CX-Cable
Origin	Hangzhou Zhejiang
HS Code	8544491100
Production Capacity	20000boxes/Per Month

Product Description

Factory Price AMP UTP Cat6 UTP Cables Network Cable UTP Cat6 Patch Cord 1.5 M

Construction:



1. Conductor: 0.50±0.01mm(24AWG) Bare copper
2. Insulation: 0.90±0.03mm HDPE
3. Cores/Pairs: 8/4
4. Single/Double Sheath: 5.0±0.3mm PVC (PE, LSZH)

Options: Jelly Compound, Jacket: UV, RoHS

Conductor Resistance	Max. 9.38 ohm/100m
Resistance Unbalance	Max. 2%
Insulation Resistance	150 ohm/KM
Mutual Capacitance	Max. 5600pF/100m
Capacitance Unbalance	Max. 330pF/100m
Impedance	100+/-15 ohm
Spark Test	2000V
Velocity of Propagation	67%

echnical Performance:

	Attenuation	RL	Next	PS Next
(Mhz)	(dB/100M)	(dB)	(dB)	(dB/100m)
1MHz	2.0	20	65.3	63.5
4MHz	4.1	23	56.3	54.2
8MHz	5.8	24.5	52.4	50.5
10MHz	6.6	25	51.3	49.2
16MHz	8.2	25	49.3	47.4
20MHz	9.3	25	48.8	46.9
25MHz	10.4	24	45.3	43.4
31.25MHz	11.7	23	43.0	41.8
62.5MHz	17.0	21	39.2	37.2
100MHz	22.0	20	36.3	34.4

Material

Type	Sheath	Insulation	Plug	Plug Spring Leaf	Plug Jacket	Conductor	Conductor Wire Gauge
PVC	PVC	HDPE	Flame-retardant Polycarbonate	Phosphor-bronze gilding	PVC	Bare Copper	Multi-strand 24AWG
LSZH	LSZH PE	LSZH	Flame-retardant Polycarbonate	Phosphor-bronze gilding	LSZH PE	Bare Copper	Multi-strand 24AWG

Transmission Performance

Frequency (MHz)	NEXT (2M) dB(Min)	NEXT (5M) dB(Min)	NEXT (10M) dB(Min)	Return Loss dB(Min)
10	54.5	53.7	52.8	22.8
20	48.6	47.9	47.1	23.7
25	46.7	46.0	45.3	24.0
31.25	44.8	44.2	43.6	23.0
62.5	39.0	38.5	38.1	20.0
100	35.1	34.8	34.6	18.0

(All dates above are lab testing results, the actual testing results are not the same as these dates,
based on the actual testing results.)
